FACEM
Provenance Studies on Ancient Pottery in the Mediterranean
PAN-SOL-A-2, M 193/12, scale bar 0.2mm
PAN-SOL-A-2, M 193/12, scale bar 0.5mm
PAN-SOL-A-2, M 193/12, 25x
PAN-SOL-A-2, M 193/12, 16x
PAN-SOL-A-2, M 193/12, 8x
| | object data | | fabric description | | archaeometry | | petrography | | |
| sample no |
M 193/12
representative sample for PAN-SOL-A-2 |
| fabric type |
PAN-SOL-A-2
|
| supposed site of production |
Palermo/Panormos-Solunto/Solus |
| sample taken |
March 2018, by Teresa Arena |
| |
Context Data
|
| site of discovery |
Monte Porcara Survey |
| registration code of context |
EL3 |
| registration code of object |
EL3-03A |
| |
Object
|
| ware |
Transport Amphorae |
| object form |
Amphora |
| object type |
Western Greek, Gassner rim 2 |
| chronology of object |
Greek-Late Archaic 510-480 |
| fragmentation |
rim |
| dimensions |
diameter: 14.4cm (rim); height: 9cm |
| surface description |
slipped white 10 YR 8/2 |
| drawing |
|
| publication |
Bechtold 2020, fig. 4,2 |
| | object data | | fabric description | | archaeometry | | petrography | | |
| |
Visual Examination of Fresh Break
|
| visual examination of fresh break |
Reddish brownish clay with a good amount of small visibile inclusions of white-yellowish colour |
| colour of fresh break |
5 YR 6/6; 7.5 YR 6/4 (core) |
| texture of fresh break |
granular |
| hardness |
hard |
| |
Observation Under the Binocular Stereoscope
(all lengths in mm)
|
| porosity |
void form: vughy; void length: 0.04-0.40-75 |
| inclusions |
length: 0.04-08-0.40 |
| sorting |
well sorted silt |
| |
Inclusions
(all lengths in mm)
|
|
calciumcarbonate |
very frequent, well rounded; rounded, very spherical, white/yellowish, 0.04-08-0.40 |
|
carbonate pseudomorphoses |
very frequent, well rounded; rounded; subangular, spherical, whitish/yellowish, 0.04-08-0.40 |
|
quartz |
rare, well rounded; rounded, very spherical, greyish/transparent, 0.08-12 |
| | object data | | fabric description | | archaeometry | | petrography | | |
| applied method for sample analysis |
thin section |
| analysis author |
Montana/Randazzo |
| | object data | | fabric description | | archaeometry | | petrography | | |
| sample number |
M 193/12 |
| inventory number |
EL3-03A |
| name of author |
Giuseppe Montana - Luciana Randazzo |
| institution of author |
Department of Earth and Marine Sciences (DiSTeM) - University of Palermo |
| contact information of author |
giuseppe.montana@unipa.it; luciana.randazzo@unipa.it |
| |
Temper Grains
|
| |
Microstructure
|
| areal distribution |
moderately homogeneous |
| packing (% area) |
medium (10-20%) |
| size/granulometry (mm) |
common:
very fine (0.04-0.1mm), fine (0.1-0.2mm), medium (0.2-0.5mm)
|
| maximum grain size (mm) |
0.4 |
| sorting |
scarce-serial |
| roundness |
angular |
| |
Composition
|
| minerals |
prevalent: Monocrystalline Quartz
sporadic: Polycrystalline Quartz, Orthoclase
rare: Plagioclase, Muscovite
|
| rock fragments |
sporadic: Sedimentary (Chert)
|
| other compositional/textural features |
common: Microfossils, Micritic Clots
|
| quartz grains |
angular |
| |
Groundmass
|
| |
Texture
|
| texture |
not homogeneous (patchy) patchy: frequent |
| optical activity |
inactive |
| degree of sintering |
well sintered |
| |
Porosity
|
| voids/pores abundance (area) |
medium (10-30%) |
| voids/pores size |
prevalent: tiny (<0.01mm), small (0.01-0.1mm), medium (0.1-1mm)
|
| voids/pores orientation |
none |
| voids/pores shape |
prevalent: irregular, rounded, cast
|
| |
Clay Composition
|
| clay composition |
ca-rich |
| |
Estimations from Microscopy/Interpretation
|
| |
Interpretation
|
| firing temperature |
well fired |
| refinement of raw clay |
bad |
| refinement of temper/clasts |
sieved natural sand |
| modelling technique/fabrication |
use of wheel |
Cite this page as: FACEM - http://facem.at/pan-sol-a-2
