VEL-CBM-4

VEL-CBM-4, M 8/47, 25x

VEL-CBM-4, M 8/47, 16x

VEL-CBM-4, M 8/47, 8x

object data

fabric description

archaeometry

sample no	M 8/47
fabric type	VEL-CBM-4
supposed site of production	Velia / Elea
sample taken	September 1996, by Verena Gassner, Institute of Classical Archaeology, Vienna University
	Context Data
site of discovery	Velia / Elea Late Archaic mudbrick houses beneath Insula II, room 11, trench 6/92, level 4
registration code of context	6002/92
registration code of object	6002/92-36
	Object
ware	Ceramic Building Materials
object form	Tile (cross tile)
fragmentation	fragmentation not specified
surface description	wiped

	Visual Examination of Fresh Break
visual examination of fresh break	reddish yellow and dark reddish grey, hackly; numerous fine to very large white particles, some large dark grey inclusions
colour of fresh break	5YR5/6
texture of fresh break	irregular
hardness	very hard
	Observation Under the Binocular Stereoscope (all lengths in mm)
porosity	10%; void form: vughy; void length: 0.12-4
inclusions	20%, length: 0.04-3.2
sorting	unsorted
	Inclusions (all lengths in mm)
brown inclusions	frequent, angular, spherical, brown, 0.4-2.4
grey inclusions	frequent, angular, elongate, dark grey, 0.24-3.2
mica	frequent
quartz	very frequent, angular, spherical, clear; white, 0.12-2.4
reddish inclusions	inrrequent, rounded, subelongate, dark red, 0.12-1.6
white inclusions	infrequent, rounded, elongate, white, 0.2-1

applied method for sample analysis	thin section and heavy mineral analysis
analysis author	Roman Sauer
petrographic mineralogical type	RVZ01

Cite this page as: FACEM - http://facem.at/m-8-47

Distribution of fabric type
“VEL-CBM-4”

Velia / Elea Velia / Elea Velia / Elea Velia / Elea Velia / Elea Velia / Elea

production discovery

Representative sample for
“VEL-CBM-4”

M 8/48

There are 2 more samples assigned to fabric type
“VEL-CBM-4”.

Fabrics of Velia: The classification of fabrics is based upon the macroscopic analysis of all diagnostic fragments\rof the material of studied contexts of the Austrian excavations. These comprise a context\rof the Early Classical period in the Lower town of Velia...

Ceramic Building Materials of Velia: Description of observed fabricsThe five types distinguished by microscopic analysis are based upon one petrographical-mineralogical type (RVZ01) with its subtypes RVZ01a and RVZ01b. The fabrics show the char-acteristics generally observed with all Velinian fabrics, consisting of the lack of any car-bonatic inclusions or carbonate?pseudomorphoses,

I mattoni bollati di Velia: I laterizi prodotti a Velia in età ellenistica, di largo impiego nelledilizia pubblica,rappresentano una produzione peculiare per caratteristiche tipologiche e morfologiche e persistema di bollatura

Pottery production at Velia: Ceramic raw materials and archaeometric analyses: IntroductionThe local production of pottery, bricks and tiles has been assumed for Velia as well as for many other colonies in Magna Graecia at a rather early stage of research, but the characteristics and the development of this production remained unknown for a long time…
