FACEM
Provenance Studies on Ancient Pottery in the Mediterranean
HIM-A-1, M 179/158, scale bar 0.2mm
HIM-A-1, M 179/158, scale bar 0.5mm
HIM-A-1, M 179/158, 25x
HIM-A-1, M 179/158, 16x
HIM-A-1, M 179/158, 8x
| | object data | | fabric description | | archaeometry | | petrography | | |
| sample no |
M 179/158
representative sample for HIM-A-1 |
| fabric type |
HIM-A-1
|
| supposed site of production |
Himera |
| sample taken |
February 2018, by Babette Bechtold, Institute of Classical Archaeology, Vienna University |
| |
Context Data
|
| site of discovery |
Himera Necropoli Ovest |
| registration code of context |
W373 |
| registration code of object |
W373 - HA10242 |
| |
Object
|
| ware |
Transport Amphorae |
| object form |
Amphora |
| object type |
Western Greek, Gassner rim 3 |
| chronology of object |
Greek-Late Archaic 510-475 BC |
| fragmentation |
profile |
| dimensions |
diameter: 9.2cm (rim), 3.3 (peg)cm (base); height: 48cm |
| surface description |
slipped pinkish slip 7.5 YR 8/3 |
| drawing |
|
| photo |
|
| publication |
Bechtold and Vassallo 2025, 298-299, cat. 407; Bechtold et al. 2019, 7-8, fig. 5,1. |
| | object data | | fabric description | | archaeometry | | petrography | | |
| |
Visual Examination of Fresh Break
|
| visual examination of fresh break |
Compact clay of brownish-pinkish colour with whitish visible inclusions of small size and sporadic white-greyish of big size |
| colour of fresh break |
7.5 YR 6/4 and 5 YR 6/6 |
| texture of fresh break |
granular |
| hardness |
hard |
| |
Observation Under the Binocular Stereoscope
(all lengths in mm)
|
| porosity |
void form: Vughy;Holes;Chamber (some); void length: 0.04-06-0.52 |
| inclusions |
length: 0.04-0.83-87 |
| sorting |
bimodal: poorly-sorted sand in well-sorted silt |
| |
Inclusions
(all lengths in mm)
|
|
calciumcarbonate |
infrequent, subangular;subrounded, subspherical;spherical, white (and some cristalyzed), 0.16-0.83-87 |
|
carbonate pseudomorphoses |
very frequent, subrounded;rounded;well rounded, subspherical;very spherical, yellowish, 0.04-0.40 |
|
mica |
frequent, very angular, subspherical, shiny, 0.04-2-0.06-08 |
|
quartz |
infrequent, subangular;rounded, subspherical;spherical;very spherical, greyish-transparent, 0.04-0.16-18 |
|
reddish inclusions |
rare, rounded, spherical, red, /-0.05 (media) |
| | object data | | fabric description | | archaeometry | | petrography | | |
| applied method for sample analysis |
thin section |
| analysis author |
Montana/Randazzo |
| publication (of analysis) |
Montana et al. 2020, 4, tab. 1, fig. 3,A-B |
| | object data | | fabric description | | archaeometry | | petrography | | |
| sample number |
M 179/158 |
| inventory number |
W373 HA10242 |
| name of author |
Giuseppe Montana - Luciana Randazzo |
| institution of author |
Department of Earth and Marine Sciences (DiSTeM) - University of Palermo |
| contact information of author |
giuseppe.montana@unipa.it; luciana.randazzo@unipa.it |
| |
Temper Grains
|
| |
Microstructure
|
| areal distribution |
moderately homogeneous |
| packing (% area) |
medium (10-20%) |
| size/granulometry (mm) |
prevalent:
very fine (0.04-0.1mm)
common:
fine (0.1-0.2mm), medium (0.2-0.5mm)
sporadic:
coarse (0.5-2mm)
|
| maximum grain size (mm) |
0.8 |
| sorting |
scarce-serial |
| roundness |
angular |
| |
Composition
|
| minerals |
prevalent: Monocrystalline Quartz
common: Polycrystalline Quartz, Orthoclase
sporadic: Plagioclase, Muscovite
|
| rock fragments |
rare: Magmatic (plutonic) (Granitoid)
|
| other compositional/textural features |
sporadic: Microfossils, Micritic Clots
|
| quartz grains |
angular |
| |
Groundmass
|
| |
Texture
|
| texture |
moderately homogeneous patchy: sporadic |
| optical activity |
inactive |
| degree of sintering |
well sintered |
| |
Porosity
|
| voids/pores abundance (area) |
medium (10-30%) |
| voids/pores size |
prevalent: tiny (<0.01mm), small (0.01-0.1mm), medium (0.1-1mm)
|
| voids/pores orientation |
partial |
| voids/pores shape |
prevalent: irregular, vesicular, cast
|
| |
Newly Formed Phases
|
| newly formed phases |
common: secondary calcite
|
| |
Estimations from Microscopy/Interpretation
|
| |
Interpretation
|
| firing temperature |
well fired |
| refinement of raw clay |
acceptable |
| refinement of temper/clasts |
sieved natural sand |
| modelling technique/fabrication |
use of wheel |
Cite this page as: FACEM - http://facem.at/him-a-1
